Choosing
Smart Solutions
The intelligent, EMD -engineered NeuroSmart System recognizes whether a Trepan Adapter or high-speed Handpiece is connected to the motor.
At the same time as the Trepan Adapter is connected by the user, the Control Unit automatically sets for its most optimal speed for Cranial Perforators, preventing inappropriate speed starting. For maximum patient protection, speed drive is automatically optimized to ensure perforation starts at appropriate RPM. Therefore, with NeuroSmart High Speed Motor System the risk of an accidental high-speed start is completely avoided. When the adapter is disconnected, the control unit resets to latest speed use of High-Speed Mode.
- Outstanding Motor Performance of 120W
- Cost-Effective Solution – One Motor of All Attachments
- Speed Range 10.000-80.000 rpm
- Touch Screen Display for Easy Handling and Cleaning
Integrated Irrigation Pump with 5-degree Adjustment
Automatic Handpiece Detection for Maximum Safety
One-Click Connection of System Elements
One-Click Connection of System Elements
One-Click Connection of System Elements
One-Click Connection of System Elements
Motor System
We believe that
Functionality and Design
create work of art.
Either we are working on a new product development or we are rethinking an older design, our top priority is creating high-end products that comply with the challenges of the time, both in terms of function and usability.
Touch screen
front panel
With its one-piece glass front panel, the NeuroSmart Control Unit was designed with medical hygiene and user practicality
in mind. The touch screen display offers easy handling and all-inclusive cleaning options.
The user-friendly menu navigation is further supported by intelligent High Speed and Perforation mode detection.
Automatized
Mode Setup
Connection and disconnection of the Trepan Adapter results in an immediate, automatized change of user modes and display functions.
Light/dark
appearance
The user has the possibility to switch between light and dark view modes at any point during procedure.
Screen brightness is easily adjustable according to the needs of operating environment.
Integrated
irrigation pump
During neurosurgical procedures, it is essential to ensure about proper cooling at surgical area. NeuroSmart Control Unit features integrated irrigation pump with variable flow control.
Superb
motor performance
Highly cost-efficient, due to its high-excursion motor power, the NeuroSmart High Speed Motor by itself manages to drive the entire range of EMD Handpiece attachments at appropriate speed. Using One-Click Technology, the complete range of Hand, – and Nosepiece tools are easily connected to the motor by a single snapping movement.
Integrated bend relief to prevent cable torsion and increase protection of connection.
Cable Connected
Footswitch
The combined Footswitch pedal is used to start/stop motor operation, while push button controls the start/stop function of the integrated pump.
The Footswitch construction complies with IP X7 standard and is therefore easy to clean and disinfect.
Pedal and push button positioning delivers comfort even during longer user times.
Craniotome Handpieces
Each EMD Handpiece collection is made from stainless steel, guaranteeing long product life. With a purposefully sleek design, the clean shape and surface makes our Craniotome Handpiece especially easy to clean. The ergonomic Pen-Grip Solution allows comfortable use and a stable grip during operation.
- 80,000 rpm
- EMD Craniotome Handpieces are designed for both adult and pediatric surgery
- EMD offers three footed Duraguards; one Laminotome Head; one Specialty Head for sinus
- Quick and easy release chuck of Duraguards
The One-Click Technology provides easy connection of the Craniotome Handpieces by simply snapping it to the motor.
Both the inserted craniotome cutter and duraguard are simultaneously locked in position with rotary knob. For greatest safety, start of the motor is not possible until rotary knob is locked.
For more user support, duraguards and craniotome blades are marked with size identifiers.
Duraguards are available in fixed and rotary configurations.
The range also includes additional models for special application areas. E.g. special head for craniotomy nearby the sinus or duraguards with increased head length for laminotomy.
Standard Handpieces
Each EMD Handpiece collection is made from stainless steel, guaranteeing a long product life. Featuring a purposefully sleek design, the clean shape and surface makes our Standard Handpieces especially easy to clean. The ergonomic pen-grip solution allows comfortable use and a stable grip during operation.
The One-Click Technology provides easy connection of the Standard Handpieces by simply snapping it to the motor.
Both the inserted tool and the handpiece are simultaneously locked in position with a rotary knob. For greatest safety, start of the motor is not possible until rotary knob is locked.
The special Tool Grasping Technology of attachments supports product selection and economic operation.
- 80,000 rpm
- Standard Handpieces are compatible with burrs ø 2,3mm
Angled Handpieces
Burrs with benefits
Each EMD®Handpiece collection is made of stainless steel, guaranteeing a long product life. Featuring a purposefully sleek design, the clean shape and surface makes our angled handpieces especially easy to clean. The ergonomic pen-grip solution allows comfortable use and a stable grip during operation.
The One-Click Technology provides easy connection of the Angled Handpieces by simply snapping it to the motor.
Both the inserted tool and the handpiece are simultaneously locked in position with rotary knob.
For greatest safety, start of the motor is not possible until rotary knob is locked.
The special Tool Grasping Technology of attachments supports product selection and economic operation.
User-friendly and cost-efficient hs tools are available with the most commonly used geometries.
Thanks to the special tool grasping technology, all Standard and Angled EMD® Neuroline handpieces are to be used with uniform-sized burrs and tools.
Slim Handpieces
Each EMD Handpiece collection is made from stainless steel, guaranteeing a long product life. Featuring a sleek design, a clean shape and surface makes our Slim Handpieces especially easy to clean. The ergonomic pen-grip solution allows comfortable use and a stable grip during operation.
Several neurosurgical applications require more precise access to the operating area.
Slim Attachments are detachable models of an angled handpiece and small-bore nosepieces.
Slim Attachments are mainly used in spine surgery applications. All handpiece and nosepiece combination are well balanced which is a great benefit during long operations.
- Speed: 25,000 rpm
- Slim Nosepieces are compatible with burrs ø 1.0mm
Trepan Adapter
With full stainless-steel finish, the new generation emd Trepan Adapter makes cranial perforation more efficient and easier thanks to its integrated smart technology.
The speed reducer features Automatic Trepan Mode recognition for the NeuroSmart Control Unit. Ergonomic handle for a comfortable, stable grip. Adapter is available with Hudson end connection.
Thanks to the One-Click Connection, the Trepan Adapter can be simply mounted on the motor. The perforator lock/release knob can be easily operated with the thumb.
The ergonomic handle is very comfortable to hold, and its surface finish allows a secure grip.
- Speed: 1,100 rpm
- EMD Trepan Adapter accepts Hudson end connection
- To be used with NeuroSmart HS Motor and Cranial Perforators for skulls 3.0mm and 1.5mm thick
